Wood drying complex

The drying complex is designed for quick drying of industrial wood – obtaining firewood, which are widespread in developed countries, as well as for preparing raw materials for the carbonization process

    telegram whatsapp viber

    Description

    Drying complex for quick drying of technical wood and obtaining firewood, which is widespread in developed countries.

    Developing the drying complex, the company GreenPower took into account all the necessary parameters of the drying process of the wood. Wood drying involves a list of peculiarities, caused by the necessity of speeding up the process of moisture evacuation out of splitwood.

    The main difference between wood drying and sawdust drying is a higher drying agent temperature necessary for the increase of the speed of moisture evaporation from wood surface.

    A high coefficient of efficiency. We have reached this due to the completely new method of wood drying: direct contact of wood with heat carrier moving at a fast pace. Due to the fact that raw material is carried in trolleys, it is possible to use the working space of the chamber maximum efficiently.

    The functions of the control of the heat carrier temperature at the outlet from the heat generator and at the inlet to the chamber allows prevention of «wood cementation», a common problem where temperature regime is incorrectly regulated.

    Drying chambers of the company GreenPower are equipped with a heat pump and other systems of warmth recuperation and condensation. The main principle of drying lies in functioning of the systems of ingoing and outgoing air. The heated air is directed to the loaded trolleys and supplies heat, then it saturates with evolving from wood moisture and is displaced by incoming dry hot air.

      APPLICATION

      1. To prepare raw materials for the carbonization process
      2. For drying firewood – fireplace firewood
      3. For drying other materials

      Completeness of the equipment

      ItemDescription
      1Heat generator with gas-air exchangerProvides heating of drying agent (of air) for drying process
      2Gas-air exchangerEngine power, 11 kW,
      Productivity 8000 m³/hour, weight 540 kg.
      3Smoke exhauster DN-9
      4Wood drying chamberCan be made using different materials of different volume
      5Chimney with insulation and deflectorHeight not less than 12 linear meters. Material – ordinary steel/corrosion-resistant plate
      6Trolleys for raw materialCan be made of different volume

      Main specifications of Wood drying equipment

      ItemSpecifications
      1Amount of drying chambers1-2
      2Number of trolleysSubject to approval
      3Effective volume of trolleysSubject to approval
      4Productivity for dry raw material, depending on the moisture and size10-15 m³/day
      5Heat generator loading volume0,3 m³
      6Estimate wood consumption for heat generator35 kg/hour
      7Drying time up to 5% of moistureDepends on the chamber volume, primary moisture and wood size
      8Drying agent temperature180-200 ͦС
      9Heat carrier circulation patterncollector
      10Download typetrack-guided on rolls/using load-transfer device
      11Material of chamber wallZinc plated /stainless steel plate
      12Control and Measuring Devices and Alarm signaling-sirenYes
      13Power consumption12 kW
